Cummins 4BT

  • 6 Cylinders ISDE Diesel Engine Complete 185hp-300hp
  • 6 Cylinders ISDE Diesel Engine Complete 185hp-300hp
  • 6 Cylinders ISDE Diesel Engine Complete 185hp-300hp
  • 6 Cylinders ISDE Diesel Engine Complete 185hp-300hp
6 Cylinders ISDE Diesel Engine Complete 185hp-300hp6 Cylinders ISDE Diesel Engine Complete 185hp-300hp6 Cylinders ISDE Diesel Engine Complete 185hp-300hp6 Cylinders ISDE Diesel Engine Complete 185hp-300hp

6 Cylinders ISDE Diesel Engine Complete 185hp-300hp

  • Brand Name: Cummins
  • Stroke: 4 Stroke
  • Dimension(L*W*H): 120cm*120cm*120cm
  • Weight: 450kg
  • Product description: 6 Cylinders ISDE Diesel Engine Complete 185hp-300hp
  • INQUIRY

Quick Details

Condition:New

Usage:trucks,loaders,excavators,etc.

Fuel:Diesel

Cylinder:Multi-cylinder

Cold Style:Air-cooled

Start:Electric Start

Place of Origin:Hubei, China (Mainland)

Model Number:ISDE, ISDe

Certification:EPA

Warranty:1 Year, 12 months

Manufacturer:Cummins

Apply to:truck, excavator,crane,loader,boat

Color:yellow or black

Packaging & Delivery

Packaging Details:Wooden packing or according to customer's requirements.

Delivery Time:5 -10 days

Engine serial Cummins ISDe140-30 Cummins ISDe160-30 Cummins ISDe160-30 Cummins ISDe200-30 Cummins  ISDe210-30 Cummins     ISDe210-30 Cummins    ISDe230-30 Cummins    ISDe245-30 Cummins    ISDe270-30 Cummins    ISDe285-30
Cylinders 6 6 6 6 6 6 6 6 6 6
Type 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line
Displacement 4.5L 6.7L 6.7L 6.7L 6.7L 6.7L 6.7L 6.7L 6.7L
Stroke*Bore 124x107mm
Max Output 103KW 118KW 118KW 147KW 155KW 155KW 169KW 180KW 198KW 210KW
Horsepower 140HP 160HP 160HP 200HP 210HP 210HP 230HP 245HP 270HP 285HP
Torque 450N.m 500N.m 500N.m 550N.m 800N.m 800N.m 900N.m 925N.m 970N.m 970N.m
Engine Type

Electric Control System,

enhancemen high pressure common rail,

Particulate filter

Electric Control System, enhancemen

high pressure common rail,

Particulate filter

Electric Control System, enhancemen

high pressure common rail,

Particulate filter

IS,

 Enhancemen High Pressure Common Rail,

DPF

Electric Control System,

 enhancemen high pressure common rail,

Particulate filter

Electric Control System,

enhancemen high pressure common rail,

Particulate filter

Electric Control System,

enhancemen high pressure common rail,

Particulate filter

IS,

Enhancemen High Pressure Common Rail,

DPF

Electric Control System,

enhancemen high pressure common rail,

Particulate filter

Electric Control System,

enhancemen high pressure common rail,

Particulate filter

Peak Torque Speed (r/min) 1400 1300 1300 1400r/min 1400 1400 1400 1200-1700r/min 1400 1400
Compression Ratio 17.3
Firing Order 1-3-2-4
Rated Speed 2500RPM 2700RPM 2700RPM 2700RPM 2500RPM 2500RPM 2500RPM 2500RPM 2500RPM 2500RPM
Engine serial Cummins ISDe140-40 Cummins ISDe160-40 Cummins ISDe180-40 Cummins ISDe200-40 Cummins ISDe210-40 Cummins   ISDe230-40 Cummins   ISDe245-40 Cummins     ISDe270-40 Cummins   ISDe285-40 Cummins        ISDe300-40
Cylinders 4 4 4 4 6 6 6 6 6 4
Cylinder Type 4 cylinder in-line 4 cylinder in-line 4 cylinder in-line 4 cylinder in-line 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line 6 cylinder in-line 4 cylinder in-line
Displacement 4.5L 4.5L 4.5L 4.5L 6.7L 6.7L 6.7L 6.7L 6.7L 4.5L
Bore*Stroke 107*124mm 107*124mm 107*124mm 107*124mm N/A 107*124mm 107*124mm 107*124mm 107*124mm
Net Weight N/A 366KG 366KG 366KG 460KG 460KG 460KG 460KG 460KG
Engine Size 901*723*819mm 810*720*820mm 810*720*820mm N/A N/A 1072*735*842mm 1072*735*842mm 1072*735*842mm 1072*735*842mm
Max Output 103KW 118KW 132KW 140KW 155KW 169KW 180KW 198KW 210KW 221KW
Horsepower 140HP PREVIOUS：Genuine Cummin ISBE diesel engine NEXT：Hot Sale DCEC QSL8.9 Diesel Engine Powerful Control System
